Flow Rate Sensor

Flow Rate Sensor

Flow Rate Sensor

$139.00

The Flow Rate Sensor measures the velocity of water in studying the discharge, flow patterns, and sediment transport of a stream or river.

ORDER CODE: FLO-BTA Category

The Flow Rate Sensor can be used for environmental or Earth science studies. Flow rate data can be used to calculate the discharge value for a stream or determine the sediment transport of a stream. The Flow Rate Sensor includes 3 riser rods, which enable the impeller to be placed at fixed depths, and is equipped with a 5 m cable so your data-collection equipment can stay on shore. The Flow Rate Sensor also separates into four sections for easy transport and convenient storage.

Flow Rate Sensor - Tech Tips with Vernier
Flow Rate Sensor - Tech Tips (8:16)

Specifications

  • Range: 0 to 4.0 m/s (0 to 13 ft/s)
  • Accuracy: ±1% of full-scale reading
  • Typical Resolution: 0.0012 m/s
  • Response time:
    • 98% of full-scale reading in 5 seconds
    • 100% of full-scale in 15 seconds
  • Temperature range (can be placed in): 0 to 70°C

Experiments

Middle School (1 experiments)
High School (1 experiments)
College (1 experiments)

Requirements

Choose a platform below to see its compatibility requirements.

LabQuest
InterfaceLabQuest App
LabQuest 3Full support
LabQuest 2Full support
LabQuestFull support
Computers
Software
InterfaceGraphical AnalysisLogger Pro (discontinued)Logger Lite (discontinued)
LabQuest MiniFull supportFull supportFull support
LabQuest 3Full supportFull supportIncompatible
LabQuest 2Full supportFull supportFull support
LabQuest StreamFull support 1Full supportFull support 1
Go!LinkFull supportFull supportFull support
LabQuestFull supportFull supportFull support
LabProIncompatibleFull supportFull support

Compatibility Notes

  1. Connect LabQuest Stream via USB. Wireless connection is not supported.
Chromebook
Software
InterfaceGraphical Analysis
LabQuest MiniFull support
LabQuest 3Full support
LabQuest 2Full support
LabQuest StreamFull support 1
Go!LinkFull support
LabQuestFull support

Compatibility Notes

  1. Connect LabQuest Stream via USB. Wireless connection is not supported.
iOS
Software
InterfaceGraphical AnalysisGraphical Analysis GW
LabQuest StreamFull supportFull support
LabQuest 3Full support 1Full support 1
LabQuest 2Full support 1Full support 1

Compatibility Notes

  1. iOS and Androidâ„¢ devices can only connect to LabQuest 2 or LabQuest 3 via Wireless Data Sharing.
Android
Software
InterfaceGraphical AnalysisGraphical Analysis GW
LabQuest StreamFull supportFull support
LabQuest 3Full support 1Full support 1
LabQuest 2Full support 1Full support 1

Compatibility Notes

  1. iOS and Androidâ„¢ devices can only connect to LabQuest 2 or LabQuest 3 via Wireless Data Sharing.
Arduino
Software
InterfaceArduino
Vernier Arduino® Interface ShieldFull support
LabVIEW
Software
InterfaceNI LabVIEW
SensorDAQFull support
Vernier myDAQ AdapterFull support 1
Go!LinkFull support
LabQuest MiniFull support
LabQuest StreamFull support
LabQuest 3Full support
LabQuest 2Full support
LabQuestFull support

Compatibility Notes

  1. You can only read the raw count/raw voltage output by this sensor. You must do the programming to convert to proper sensor units.
Texas Instruments
Software
InterfaceEasyDataDataMateTI-84 SmartViewDataQuestTI-Nspire Software
EasyLinkFull support 1IncompatibleFull support 2Full supportFull support 2
CBL 2Full support 3Full support 3 4IncompatibleIncompatibleIncompatible
LabProFull support 3Full support 3 4IncompatibleIncompatibleIncompatible
TI-Nspire Lab CradleIncompatibleIncompatibleIncompatibleFull supportFull support

Compatibility Notes

  1. Use with TI-84 Plus calculators only.
  2. Requires an Easy to Go! adapter
  3. CBL 2 and LabPro interfaces cannot be used with TI-84 Plus CE calculators.
  4. DataMate cannot be used with color screen TI-84 Plus calculators; use EasyData with these calculators.

What's Included

  • Vernier Flow Rate Sensor

Accessories

Support

Educational use only: Vernier products are designed for educational use. They are not appropriate for industrial, medical, or commercial applications.
